Q10
10.1 inch Full HD 1500 cd/m² field monitor with 2x 12G-SDI and 1x HDMI. Made for 8K workflows in broadcast and live events.
- Screen size: 10 inch
- Display resolution: 1920 x 1200
- Brightness: 1500 cd/m²
- Contrast: 1000:1
- 10.1 inch 1920 x 1200 LCD display, 1500 cd/m², 1000:1 contrast, 16:10 aspect ratio
- 2x 12G-SDI and 1x HDMI 2.0 input/output, 4K 60Hz support
- HDR ST 2084 (300/1000/10000 cd/m²) and HLG; 3D LUT (.cube); 17 default camera logs plus 6 user LUTs
- Tally connector; 12G-SDI PIP and PBP functions
-
A11
10.1 inch Full HD 320 cd/m² on-camera video monitor with 1x 3G-SDI and 1x HDMI.
- Screen size: 10 inch
- Display resolution: 1920 x 1200
- Brightness: 320 cd/m²
- Contrast: 1000:1
- 10.1 inch 1920 x 1200 display, 320 cd/m², 1000:1 contrast, 16:10 aspect ratio
- 1x 3G-SDI, 1x HDMI 1.4, 1x VGA, input and loop-through output
- 4K HDMI passthrough (2160p 24/25/30); 3G-SDI 720p to 1080p support
- Glass+Glass technology; F1 & F2 user-definable shortcut buttons
-
Q7-12G
7 inch Full HD 2000 cd/m² field monitor with 2x 12G-SDI and 1x HDMI. Made for 8K workflows in broadcast and live events.
- Screen size: 7 inch
- Display resolution: 1920 x 1200
- Brightness: 2000 cd/m²
- Contrast: 1200:1
- 7 inch 1920 x 1200 LCD display, 2000 cd/m² high-brightness, 1200:1 contrast, 16:10 aspect ratio
- 2x 12G-SDI and 1x HDMI 2.0 input/output, 4K 60Hz support
- HDR ST 2084 (300/1000/10000 cd/m²) and HLG; 3D LUT (.cube); 17 default camera logs plus 6 user LUTs
- Tally connector; 12G-SDI picture-in-picture
-
Q5
5.5 inch Full HD 500 cd/m² on-camera video monitor with 1x 3G-SDI and 1x HDMI.
- Screen size: 5 inch
- Display resolution: 1920 x 1080
- Brightness: 500 cd/m²
- Contrast: 1000:1
- 5.5 inch 1920 x 1080 LCD display, 500 cd/m², 1000:1 contrast, 16:9 aspect ratio
- 1x 3G-SDI and 1x HDMI 1.4 input/output with loop-through and SDI/HDMI cross conversion
- Waveform (Multi, Y, YCbCr, RGB), peaking, false colour, exposure, histogram, level meter; time code LTC/VITC (SDI)
- F1/F2 user-definable function buttons (default: Waveform, Scan); integrated recording info display; metal housing
-
HT5S
5.5 inch Full HD 2000 cd/m² on-camera touch screen video monitor with 1x 3G-SDI and 1x HDMI.
- Screen size: 5 inch
- Display resolution: 1920 x 1080
- Brightness: 2000 cd/m²
- Contrast: 1000:1
- 5.5 inch 1920 x 1080 LCD display, 2000 cd/m² high-brightness, 1000:1 contrast, 100% BT.709
- Capacitive touch screen, menu control via touch gestures; shortcut swipes for backlight, volume, zoom
- 1x 3G-SDI and 1x HDMI 2.0 input/output, 4K 60Hz support
- HDR ST 2084 (300/1000/10000 cd/m²) and HLG; 3D LUT (.cube); 17 default camera logs plus 6 user LUTs
-
HT10S
10.1 inch Full HD 1500 cd/m² on-camera touch screen video monitor with 1x 3G-SDI and 1x HDMI.
- Screen size: 10 inch
- Display resolution: 1920 x 1200
- Brightness: 1500 cd/m²
- Contrast: 1000:1
- 10.1 inch 1920 x 1200 LCD display, 1500 cd/m², 1000:1 contrast, 125% BT.709 / 92.5% DCI-P3, 16:10 aspect ratio
- Capacitive touch screen, menu control via touch gestures; shortcut swipes for backlight, volume, zoom
- 1x 3G-SDI and 1x HDMI 2.0 input/output, 4K 60Hz support
- HDR ST 2084 (300/1000/10000 cd/m²) and HLG; 3D LUT (.cube); 17 default camera logs plus 6 user LUTs
-
H7S
7 inch Full HD 1800 cd/m² on-camera video monitor with 1x 3G-SDI and 1x HDMI.
- Screen size: 7 inch
- Display resolution: 1920 x 1200
- Brightness: 1800 cd/m²
- Contrast: 1200:1
- 7 inch 1920 x 1200 LCD display, 1800 cd/m² high-brightness, 1200:1 contrast, 16:10 aspect ratio
- 1x 3G-SDI and 1x HDMI 1.4 input/output with loop-through; 4K HDMI (2160p 24/25/30)
- HDR ST 2084 (300/1000/10000 cd/m²) and HLG; 3D LUT (.cube); 8 default camera logs plus 6 user LUTs
- F1 and F2 user-definable function buttons; INPUT key switches HDMI and SDI sources
-
FS7
7 inch Full HD 500 cd/m² on-camera video monitor with 1x 3G-SDI and 1x HDMI.
- Screen size: 7 inch
- Display resolution: 1920 x 1200
- Brightness: 500 cd/m²
- Contrast: 1000:1
- 7 inch 1920 x 1200 IPS display, 500 cd/m², 1000:1 contrast, 16:10 aspect ratio
- 1x 3G-SDI and 1x HDMI 1.4 input and loop output, 4K passthrough (2160p 24/25/30)
- 405 g; 182 x 124 x 22 mm; compact design
- Shoe mount: 1/4 inch British Standard Whitworth (BSW) thread
-
HT7S
7 inch Full HD 2000 cd/m² on-camera touch screen video monitor with 1x 3G-SDI and 1x HDMI.
- Screen size: 7 inch
- Display resolution: 1920 x 1200
- Brightness: 2000 cd/m²
- Contrast: 1200:1
- 7 inch 1920 x 1200 LCD display, 2000 cd/m² high-brightness, 1200:1 contrast, 100% BT.709, 16:10 aspect ratio
- Capacitive touch screen, menu control via touch gestures; shortcut swipes for backlight, volume, zoom
- 1x 3G-SDI and 1x HDMI 2.0 input/output, 4K 60Hz support
- HDR ST 2084 (300/1000/10000 cd/m²) and HLG; 3D LUT (.cube); 17 default camera logs plus 6 user LUTs
-
A5
5 inch Full HD 400 cd/m² on-camera video monitor with 1x HDMI.
- Screen size: 5 inch
- Display resolution: 1920 x 1080
- Brightness: 400 cd/m²
- Contrast: 1000:1
- 5 inch 1920 x 1080 IPS display, 400 cd/m², 1000:1 contrast
- 1x HDMI 1.4 input and loop output, 4K passthrough (2160p 24/25/30)
- 118 g ultra-light; 129.6 x 80.1 x 23.6 mm compact design
- Shoe mount: 1/4 inch British Standard Whitworth (BSW) thread
-
A7S
7 inch Full HD 500 cd/m² on-camera video monitor with 1x HDMI.
- Screen size: 7 inch
- Display resolution: 1920 x 1200
- Brightness: 500 cd/m²
- Contrast: 1000:1
- 7 inch 1920 x 1200 IPS display, 500 cd/m², 1000:1 contrast, 16:10 aspect ratio
- 1x HDMI 1.4 input and loop output, 4K passthrough (2160p 24/25/30)
- 320 g; 182.1 x 124 x 20.5 mm; ultra-slim 20 mm profile
- Shoe mount: 1/4 inch British Standard Whitworth (BSW) thread
-
FS5
5.4 inch Full HD 600 cd/m² on-camera video monitor with 1x 3G-SDI and 1x HDMI.
- Screen size: 5 inch
- Display resolution: 1920 x 1200
- Brightness: 600 cd/m²
- Contrast: 1100:1
- 5.4 inch 1920 x 1200 LTPS display, 600 cd/m², 1100:1 contrast, 16:10 aspect ratio
- 1x 3G-SDI and 1x HDMI 2.0 input/output, 4K 60Hz support
- HDR ST 2084 (300/1000/10000 cd/m²) and HLG; 3D LUT (.cube); camera log (SLog2/SLog3, ArriLog, CLog, JLog, VLog, NLog)
- 295 g; 154.5 x 90 x 20 mm compact design
