Features Explore 819 Technical Data
8 inch 1280 x 768 LCD, 1000 cd/m², 800:1 contrast, 4:3 10-point PCAP touch screen optional 1x HDMI, 1x VGA, 1x USB-C; anti-glare, anti-fingerprint coating 50,000 h LED backlight life DC 9 to 36V, less than 11 W; -25°C to 75°C operating temperature 205 x 164.5 x 33 mm; 750 g; VESA 75 mm
Display
Screen size
8 inch
Aspect ratio
4:3
Native resolution
1280 x 768
Panel type
LCD
Brightness
1000 cd/m²
Contrast
800:1
Viewing angle
170°/170° (H/V)
LED lifetime
50,000 h
Optional coating
Anti-glare, anti-fingerprint
Touch screen
10-point PCAP (optional)
Connections
Video inputs
1x HDMI, 1x VGA, 1x USB Type-C
Audio
1x Built-in speaker, HDMI audio, 3.5 mm ear jack (2ch 48kHz 24-bit)
Additional connections
1x USB-A (for touch) (optional)
Video Standards
HDMI
2160p 24/25/30, 1080p 24/25/30/50/60, 1080i 50/60, 720p 50/60
VGA
1080p 24/25/30/50/60, 1080pSF 24/25/30, 1080i 50/60, 720p 50/60
USB Type-C
2160p 24/25/30/50/60, 1080p 24/25/30/50/60, 1080i 50/60, 720p 50/60
Operational Features
Sensors
Ambient light auto-dimming
Power
Input voltage
DC 9 to 36V
Power consumption
≤11 W (12V)
Environmental
Operating temperature
-25°C to 75°C
Storage temperature
-35°C to 85°C
Mechanical
Dimensions
205 x 164.5 x 33 mm
Weight
750 g
Accessories
Included
12V 2A Power Adapter, HDMI A-A Cable, USB-C - C Cable (With Screw)
Optional
Remote Control, VESA 75mm Bracket, HDMI Cable Lock
