Lilliput FA1011 · 10.1 inch monitor
Lilliput FA1011 · 10.1 inch monitor
Interactive 10.1 inch display for commercial and industrial environments. 1024 x 600, 250 cd/m². HDMI, VGA, 2x Composite. DC 12V, ≤9 W. Resistive touch optional. For kiosks, control panels, and industrial applications.
- 10.1 inch 1024 x 600 LCD, 250 cd/m², 500:1 contrast, 16:10
- 4-wire resistive touch screen optional
- 1x HDMI, 1x VGA, 2x Composite, versatile inputs
- DC 12V, ≤9 W; -20°C to 60°C operating
- 254.5 x 163 x 34 mm; 1125 g; VESA 75 mm
Display
| Screen size | 10.1 inch |
|---|---|
| Aspect ratio | 16:10 |
| Native resolution | 1024 x 600 |
| Panel type | LCD |
| Brightness | 250 cd/m² |
| Contrast | 500:1 |
| Viewing angle | 140°/110° (H/V) |
| Touch screen | 4-wire resistive (optional) |
Connections
| Video inputs | 1x HDMI, 1x VGA, 2x Composite |
|---|---|
| Audio | 1x Built-in speaker, 3.5 mm ear jack |
Video Standards
| HDMI | 1080p 50/60, 1080i 50/60, 720p 50/60 |
|---|
Power
| Input voltage | DC 12V |
|---|---|
| Power consumption | ≤9 W |
Environmental
| Operating temperature | -20°C to 60°C |
|---|---|
| Storage temperature | -30°C to 70°C |
Mechanical
| Dimensions | 254.5 x 163 x 34 mm (63.5 mm with bracket) |
|---|---|
| Weight | 1125 g |
Mounting
| VESA mount | 75 x 75 mm |
|---|
Accessories
| Included | 12V DC Adapter, Remote Control, HDMI A-A Cable, HDMI to DVI Cable, VGA Cable, 14-pin SKS Cable, CD Driver |
|---|---|
| Optional | VESA Rail Slot |
