3G-SDI/HDMI to USB 3.0 capture. 1x SD/HD/3G-SDI, 1x HDMI 1.4a, 1x 3.5 mm stereo audio. USB 3.0 Type C output up to 200 MB/s. 1080p 24/25/30/50/60, 1080pSF, 1080i, 720p, 625i, 525i. YUY2. UVC/UAC. 2ch 16 bit PCM 48 kHz. Windows 7/8/10, Linux, macOS 10.8+. OBS, Zoom, Teams. USB bus-powered, 3.5 W max. 92 x 58 x 19 mm, 205 g.
1920 x 1200 down to 640 x 360 (1920 x 1080, 1680 x 1050, 1600 x 1200, 1440 x 900, 1368 x 768, 1280 x 1024/960/800/720, 1024 x 768/576, 960 x 540, 856 x 480, 800 x 600, 768 x 576, 720 x 576/480, 640 x 480/360)
Video color space
YUY2
Capture standard
UVC (USB Video Class), UAC (USB Audio Class)
Audio sampling
48 kHz 16 bit
Operational Features
Power
Power consumption
3.5 W max (USB bus-powered)
Environmental
Operating temperature
-20°C to 60°C
Storage temperature
-30°C to 70°C
Relative humidity
20 to 90% non-condensing
Mechanical
Dimensions
92 x 58 x 19 mm
Weight
205 g
Accessories
Included
USB 3.0 A to C cable
Support
System
Windows 7/8/10, Linux (kernel 2.6.38+), macOS 10.8+
