15.6 inch 1000 cd/m² industrial panel PC with 1920 x 1080 PCAP touch, Intel processor options from Celeron to Core i7, Windows or Linux, IP65 front panel, and glove- and wet-touch support for production-line and factory HMI use.
15.6 inch 1920 x 1080 LCD, 1000 cd/m² high-brightness
10-point PCAP touch with glove and wet-touch support
Built-to-order Intel platforms: Celeron J4125, J6412, or Core i3/i5/i7
Configurable RAM up to 64 GB and storage up to 1 TB (platform dependent)
HDMI, Gigabit LAN, RS232/RS422/RS485, USB, and optional SIM and cellular (Core platforms)
IP65 front panel (water and dust resistant); -10°C to 60°C operating range
The Lilliput PC-1560 is a 15.6" Windows 10 x86 Panel PC system designed for use in monitoring and control systems. Featuring a choice of processors and associated chipsets.
With an IP64 rating as standard, a 1920 x 1080 resolution LED panel with 1000 nit brightness, and a 10 point capacitive multi-touch screen it has solid HMI credentials and can be used in a number of industries - Medical, Smart lockers, Production, and in-vehicle farming systems.
With 4GB RAM (expandable to 8GB) and a 120GB mSATA drive (upgradeable to 1TB), it offers reliable performance and delivers at a great price.
Display
Screen size
15.6 inch
Aspect ratio
16:9
Native resolution
1920 x 1080
Panel type
IPS
Brightness
1000 cd/m²
Contrast
1000:1
Viewing angle
160°/160° (H/V)
Touch screen
10-point PCAP
System
CPU
Intel Celeron J4125, J6412, or Intel Core i3/i5/i7 (built to order)
GPU
Intel UHD Graphics
Operating system
Windows 11 / Linux (optional)
RAM
4 GB default; up to 8 GB (J4125), 16 GB (J6412), or 64 GB (Core)
Storage
120 GB default; mSATA (Celeron) or M.2-SATA (Core), up to 1 TB
