HDMI to 3G-SDI mini converter: 1x HDMI type A in, 2x SD/HD/3G-SDI BNC out Pocket-size broadcast converter with full-size HDMI and SDI connectors for convenient field and studio use Converts full HD 1080p60 HDMI to professional SDI; selectable SD/HD/3G-SDI output rate HDMI input: YUV 4:2:2/4:4:4 and RGB 4:4:4; SDI output: YUV 4:2:2 SDI formats: 525i/625i, 720p, 1080i, and 1080p; HDMI input: 480i/576i, 720p, 1080i, and 1080p USB Type-C power (3.3 to 5 V), 2 W; detachable mounting bracket included 71 x 41 x 23 mm, 168 g; -20°C to 60°C operating, 3 year limited warranty
Connections
Video inputs
1x HDMI type A
Video outputs
2x SD/HD/3G-SDI (75Ω BNC)
Power input
1x USB Type-C (3.3 to 5 V)
Video Standards
HDMI
1080p 23.976/23.98/24/25/29.97/30, 1080p 50/59.94/60, 1080i 50/59.94/60, 720p 50/59.94/60, 576i 50, 480i 59.94/60
3G-SDI
1080p 23.976/23.98/24/25/29.97/30, 1080p 50/59.94/60, 1080i 50/59.94/60, 720p 50/59.94/60, 625i 50, 525i 59.94
3G-SDI compliance
SMPTE 259M, SMPTE 292M, SMPTE 424M
Colour space
YUV 4:2:2/4:4:4 and RGB 4:4:4 (HDMI input); YUV 4:2:2 (SDI output)
SDI output rate
SD/HD/3G-SDI selectable
Power
Input voltage
DC 3.3 to 5 V USB Type-C
Power consumption
2 W
Environmental
Operating temperature
-20°C to 60°C
Storage temperature
-30°C to 70°C
Relative humidity
0% to 90% non-condensing
Mechanical
Dimensions
71 x 41 x 23 mm
Weight
168 g
Mounting
Wall mount
Detachable mounting bracket included
Accessories
Included
5V Special Power Adapter, USB Cable, Mounting Bracket
