Interactive 13.3 inch display for commercial and industrial environments. 1920 x 1080, 300 cd/m². HDMI, DVI, VGA, Composite. DC 7 to 24V, ≤8 W. For kiosks, control panels, and industrial applications.
3.5 mm ear jack (2ch 48kHz 24-bit); built-in speaker
DC 7 to 24V, ≤8 W; -20°C to 60°C operating
333.5 x 220 x 34.5 mm; 1.9 kg; VESA mounting
Display
Screen size
13.3 inch
Aspect ratio
16:9
Native resolution
1920 x 1080
Panel type
LCD
Brightness
300 cd/m²
Contrast
800:1
Viewing angle
170°/170° (H/V)
Touch screen
10-point PCAP (optional)
Connections
Video inputs
1x HDMI, 1x DVI, 1x VGA, 1x Composite
Audio
3.5 mm ear jack (2ch 48kHz 24-bit), 1x Built-in speaker
Video Standards
HDMI
1080p 50/60, 1080i 50/60, 720p 50/60
Operational Features
Power
Input voltage
DC 7 to 24V
Power consumption
≤8 W
Environmental
Operating temperature
-20°C to 60°C
Storage temperature
-20°C to 70°C
Mechanical
Dimensions
333.5 x 220 x 34.5 mm
Weight
1.9 kg
Mounting
VESA mount
75 x 75 mm
Mounting Screws
4x Wall Mount Screws
Stand
Desktop Foldable Stand (optional)
Accessories
Included
12V DC adapter, HDMI A/A cable, VGA Cable, Manual, Screws for VESA mount, Audio BNC cable, Video BNC cable, Drive Disk, Open frame bracket, 4x Wall Mount Screws
