Lilliput TK1850 · 18.5 inch IP65 monitor

Interactive 18.5 inch display for commercial and industrial environments. 1920 x 1080, 1000 cd/m². HDMI 1.4b, VGA, AV. DC 12 to 24V, ≤32 W. IP65 front panel, IK07. For kiosks, control panels, and industrial applications.

1 7

£299.00 exc VAT £358.80inc VAT

Key Attributes

Display resolution 1920 x 1080
Aspect ratio 16:9
Contrast 1000:1
Touch screen PCAP
Brightness 1000 cd/m²
Screen size 18 inch

Configuration

Monitor Touch Screen Monitor

View full details

18.5 inch open frame touch screen monitor
10-point PCAP touch screen optional
1920 x 1080 LCD, 1000 cd/m², 1000:1 contrast, 16:9
1x HDMI 1.4b, 1x VGA, 1x AV, versatile inputs
HDMI 4K 30Hz passthrough; HDR support (HDR10, HLG)
IP65 front panel (NEMA 4); IK07 impact resistance; hardness 7H
Anti-glare, anti-fingerprint coating
DC 12 to 24V, ≤32 W; -10°C to 60°C operating
475 x 296 x 45.7 mm; 4.6 kg; VESA 75 mm / 100 mm

Display

Screen size	18.5 inch
Aspect ratio	16:9
Native resolution	1920 x 1080
Panel type	LCD
Brightness	1000 cd/m²
Contrast	1000:1
Viewing angle	170°/170° (H/V)
Coating	Anti-glare, anti-fingerprint
Touch screen	10-point PCAP (optional)

Connections

Video inputs	1x HDMI 1.4b, 1x VGA, 1x Audio & Video (RCA)
Audio	2x Built-in speakers, HDMI 2ch, 3.5 mm ear jack (2ch 48kHz 24-bit)
Additional connections	2x USB-A (touch, upgrade) (optional)

Video Standards

HDMI 1.4b	2160p 24/25/30, 1080p 24/25/30/50/60, 1080i 50/60, 720p 50/60
VGA	1080p 24/25/30/50/60, 1080pSF 24/25/30, 1080i 50/60, 720p 50/60
AV	1080p 24/25/30/50/60, 1080pSF 24/25/30, 1080i 50/60, 720p 50/60

Operational Features

Sensors	Ambient light auto-dimming
Markers — Aspect markers	1.85:1, 2.35:1, 4:3, 3:2
Markers — Safety marker	80%, 85%, 88%, 90%, 93%, 95%
Markers — Centre marker	On/Off
Image mirroring	Vertical flip, Horizontal flip

Power

Input voltage	DC 12 to 24V
Power consumption	≤32 W (15V)

Environmental

IP rating	IP65 front panel (IEC60529), NEMA 4 front
IK rating	IK07 (IEC62262/EN62262)
Hardness	7H
Vibration	IEC6068-2-64
Shock	IEC6068-2-27
Operating temperature	-10°C to 60°C
Storage temperature	-20°C to 60°C

Mechanical

Dimensions	475 x 296 x 45.7 mm
Weight	4.6 kg

Mounting

VESA mount	75 x 75 mm, 100 x 100 mm

Accessories

Included	15V 3A Power Adapter, 0.8 m HDMI A-A Cable, VGA Cable, 14x Screw Kits, Cable Clamps, Foam Silicone, Audio / Video Cable, Manual
Optional	VESA 75 mm / 100 mm Bracket, Remote Control
