Interactive 21.5 inch display for commercial and industrial environments. 1920 x 1080, 1000 cd/m². HDMI 1.4b, VGA, AV. DC 12 to 24V, ≤37 W. IP65 front panel. For kiosks, control panels, and industrial applications.
1920 x 1080 LCD, 1000 cd/m², 1000:1 contrast, 16:9
1x HDMI 1.4b, 1x VGA, 1x AV, versatile inputs
HDMI 4K 30Hz passthrough; HDR support (HDR10, HLG)
IP65 front panel (water and dust resistant)
DC 12 to 24V, ≤37 W; 0°C to 50°C operating
556 x 344.5 x 48.2 mm; 5.99 kg; VESA 75 mm / 100 mm
The Lilliput TK2150 monitor is a 21.5" interactive display with a 1000 cd/m² high brightness screen panel.
Ideal for use in information kiosks, or point of sale terminals. The interfaces support a wide range of customization options in addition to the existing types such as HDMI, VGA, AV, etc. Its IP65 front panel design is great for mounting into custom cut-outs.
Looking for a monitor to use in a Teleprompter? No problem - this model features both X/Y Flip and Mirroring of the input image, making it an ideal tool for the job.
Display
Screen size
21.5 inch
Aspect ratio
16:9
Native resolution
1920 x 1080
Panel type
LCD
Brightness
1000 cd/m²
Contrast
1000:1
Viewing angle
178°/178° (H/V)
Touch screen
10-point PCAP (optional)
Connections
Video inputs
1x HDMI 1.4b, 1x VGA, 1x Audio & Video (RCA)
Audio
2x Built-in speakers, HDMI 2ch, 3.5 mm ear jack (2ch 48kHz 24-bit)
